Django Table, Filter and Export With Htmx

Fundor333 | | | Reading time 3 minutes | Word count 590

########

This post is part of the Django Tricks series
  1. Django Rest Framework: Multiple post
  2. Make a Excel Django combo
  3. Django With Barcode and Qrcode
  4. Django Return Pdf With Reportlab
  5. Django List View With Show More
  6. Message and Allert With Django and Boostrap
  7. Csv From Django
  8. Django Generate Barcode With Reportlab
  9. Add Minor Things to Django for templating
  10. Htmx Django and Django Table2
  11. Django Table, Filter and Export With Htmx

Card image cap by IA Midjourney

Some time ago I wrote a blog post about Htmx and Django-table2 and all went well…

So So

No he didn’t work as I wanted so I did some editing of the code here and there.

The old one

We start with the code I didn’t change:

First the model

# blog/model.py

class Post(models.Model):
    title = models.CharField(max_length=400)
    slug = models.SlugField(max_length=400, unique=True, blank=True)
    content = models.TextAreaField()
    date = models.DateTimeField(auto_now_add=True)

The table

# blog/tables.py

import django_tables2 as tables
from blog.models import Post

class PostTable(tables.Table):
    class Meta:
        model = Post
        order_by = ("-date", "title")
        fields = ["date", "title", "slug"]

This two fragment are perfect as is so I didn’t touch them. But all the other part I reworked as I needed.

The new parts

I need to have a “universal table” for show data, with filter and export the data. And I need to have an “universal template” for all the combination Table-Export-Filter…

So I wrote one

Typing

First thing (after the model and the table) I need view with filter and exporter support. And using django-table21 all was easy.2

So I wrote this class which support all I need for using it as Htmx endpoint.

# blog/views.py

from django_tables2 import SingleTableMixin
from django_tables2.export import ExportMixin, TableExport
from django_filters.views import FilterView
from blog.model import Post

class DataHtmx(ExportMixin, SingleTableMixin, FilterView):
    model = Post
    template_name = "generic/table2.html"

    table_class = PostTable

    filterset_fields = ["title","slug", "date"]

    export_formats = (
        TableExport.CSV,
        TableExport.XLS,
        TableExport.XLSX,
        TableExport.ODS,
    )

    def get_export_filename(self, export_format):
        return f"Export Data.{export_format}"
  • ExportMixin, with the export_formats are the the export part of the view
  • SingleTableMixin is the table part of the view
  • FilterView is the filter part of the view, with filterset_fields as the field you can filter. You can also haave a filterset_class if you need

Done this I need a template. More generic template because I don’t want to rewrite the same code every time…

So here is it!

# templates/generic/table.html

{% load render_table from django_tables2 %}
{% load export_url from django_tables2 %}
{% load django_bootstrap5 %}

{% if filter  %}
  {% if 'hide_filter' not in request.GET %}
      <div class="col-12 col-md-9">
        <div class="card mb-4">
          <div class="card-header">
            <button class="btn btn-section" type="button" data-bs-toggle="collapse" data-bs-target="#filterCollapse">
              <i class="fa-solid fa-filter"></i> Filtri <i class="fa-solid fa-chevron-down"></i>
            </button>
          </div>
          <div id="filterCollapse" class="collapse">
            <div class="card-body">
              <form method="get" class="row">
                {% load django_bootstrap5 %}
                {% bootstrap_form filter.form layout='floating' %}
                  {% include 'generic/_btn_search.html' %}
              </form>
            </div>
          </div>
        </div>
      </div>
{% endif %}
{% endif %}

<div class="row">
    {% if 'hide_export' not in request.GET %}
      {% for format in view.export_formats %}
      <a  class="btn col col-sm" href="{{ request.path }}{% export_url format %}" target="_blank">
        <i class="fa-duotone fa-regular fa-download"></i> <code>{{ format }}</code>
      </a>
      {% endfor %}
    {% endif %}
    <hr>
    {% render_table table %}
</div>

This template work if you have filters, export or not.

  • the load are for django-table2 and boostrap (the last is for me, is not needed for the code)
  • ‘hide_filter’ not in request.GET check if the url has the params for hide_filter. If it is present, the template hides the filters
  • ‘hide_export’ not in request.GET check if the url has the params for hide_export. If it is present, the template hides the exports

One example for the Htmx code is the following.

<div hx-get="{% url 'blog:post_htmx' %}?date_at={{ query_date | date:"Y-m-d"  }}&hide_filter" hx-trigger="load">

In this example I had the filter set (with data form the template) and with hide_filter which hide the filters but not the exports button.

I thing this will be a stable of my django code and it can be move in a custom module for share and easy import.

  1. Django-table2    ↩︎

  2. I also use tablib   for the export and django-filter   for the filtering. ↩︎
